Hougen Mag Drills
-
HMD900 – HOUGEN MAG DRILL
$1,202.00 -
HMD904 – HOUGEN MAG DRILL
$1,289.00 -
HMD130 – HOUGEN MAG DRILL – ULTRA LOW PROFILE – 115V
$1,599.00 -
HMD905C – COOLANT
$2,145.00 -
SALE
HMD904P Permanent Magnet (NEW)
Original price was: $2,699.00.$2,299.00Current price is: $2,299.00. -
HMD920C – COOLANT
$2,399.00 -
HMD920CS – COOLANT TANK & SWIVEL
$2,599.00 -
HMD2X2 Portable Magnetic Drill
$2,699.00 -
HMD920CF – COOLANT TANK & FABKIT
$2,899.00 -
HMD927CP – COOLANT TANK & POWER FEED
$3,099.00 -
HMD918 – HOUGEN MAG DRILL
$3,499.00 -
HMD934 – HOUGEN MAG DRILL
$5,479.00
Compare All Models
 |
 HMD130 |
 HMD904 |
 HMD904P |
 HMD905 |
 HMD906 |
 HMD927 |
 HMD2MT |
 HMD918 |
 HMD917 |
 HMD934 |
||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Low Profile | Fabricating | Heavy Duty Drilling | ||||||||||
|
Cutters
|
RotaLoc Plus™ |  |
With Adapter | With Adapter | With Adapter | With Adapter | With Adapter | With Adapter | With Adapter | With Adapter | ||
| 12,000-Series | |
|
|
|
|
|
|
|
|
|||
| Copperhead™ Carbide Tipped | |
|
|
|
|
|
|
|
||||
|
Model Specifications
|
Diameter Min./ Max. | 7/16″ to 1-3/8″ (12 – 35mm) | 7/16″ to 1-1/2″ (12 – 38mm) | 7/16″ to 1-1/2″ (12 – 38mm) | 7/16″ to 1-5/8″ (12 – 41mm) | 7/16″ – 2″ (12mm – 50mm) | 7/16″ to 1-5/8″ (12 – 41mm) | 9/16″ to 1-5/8″ (14 – 41mm) | 7/16″ to 2-3/8″ (12 – 60mm) | 7/16″ to 2-3/8″ (12 – 60mm) | 5/8″ to 3-1/16″ (16 – 77mm) | |
| Depth Max. | 1″ (25mm) | 2″ (50mm) | 2″ (50mm) | 2″ (50mm) | 2″ (50mm) | 2″ (50mm) | 2″ (50mm) | 6″ (152mm) | 3″ (76mm) | 4″ (100mm) | ||
| Cutter Mounting | Bayonet Style | 3/4″ Double Flat | 3/4″ Double Flat | 3/4″ Double Flat | 3/4″ Double Flat or Fusion2™t | 3/4″ Double Flat | 3/4″ Double Flat | 3/4″ Double Flat | 3/4″ Double Flat | 3/4″ Double Flat | ||
| No-Load R.P.M. | 450 | 450 | 450 | 250 / 450 | 350 / 650 | 250 / 450 | 250 / 450 | 250 / 450 | 250 / 450 | 250 / 450 450 / 750 |
||
| Model Weight | 23.8 lbs (10.8 kg) |
28.9 lbs (13.1 kg) |
28.9 lbs (13.1 kg) |
35 lbs (15.9 kg) |
35 lbs (15.9 kg) |
43 lbs (19.5 kg) |
40 lbs (18.1 kg) |
44.2 lbs (20.1 kg) |
46 lbs (20.9 kg) |
72 lbs (32.6 kg) |
||
| Thru-the-Tool Coolant | |
|
|
|
|
|
|
|
|
|||
|
Available Accessories
|
Carrying Case Included | |
|
|
|
|
|
|
|
|
||
| Swivel Base | Optional | Optional | Optional | Optional | Optional | Optional | ||||||
| #2 Morse Taper | |
With Adapter |
With Adapter |
|||||||||
| Pipe Adapter | |
|
|
|
Manual Mode |
|
|
|
Bracket Mount |
|||
| Tap Attachment | |
|
|
|
Manual Mode |
|
|
|
||||
| Vac-Pad™ | |
|
|
|
||||||||
| Coolant Bottle | Optional | Optional | Included | Included | Included | Included | Pressurized | Included | Included | |||
| Countersink Kit | |
|
|
|
Manual Mode |
|
|
|
|
|||
| Twist Drill Adapter | |
|
|
|
Manual Mode |
|
|
|
|
|||
| Ratchet Drive | |
|
|
|
|
|
|
|
||||
| Arbor Extender | |
|
|
|
Manual Mode | |
|
|
|
|||
| Drill Chuck | |
|
|
|
Manual Mode | |
|
|
||||
| RotaLoc™ Spindle Adapter | |
|
|
|
Manual Mode | |
|
|
||||
Choose Your Depth of Cut
