Hougen Mag Drills

Compare All Models

Hougen Logo hmd130HMD130 hmd904HMD904 hmd905HMD905 hmd906HMD906 hmd927HMD927 hmd2mtHMD2MT hmd918HMD918 hmd505HMD917 hmd934HMD934
Low Profile Fabricating Heavy Duty Drilling
Cutters
RotaLoc Plus™ checkmark With Adapter With Adapter With Adapter With Adapter With Adapter With Adapter With Adapter
12,000-Series checkmark checkmark checkmark checkmark checkmark checkmark checkmark checkmark
Copperhead™ Carbide Tipped checkmark checkmark checkmark checkmark checkmark checkmark checkmark
Model Specifications
Diameter Min./ Max. 7/16″ to 1-3/8″ (12 – 35mm) 7/16″ to 1-1/2″ (12 – 38mm) 7/16″ to 1-5/8″ (12 – 41mm) 7/16″ – 2″ (12mm – 50mm) 7/16″ to 1-5/8″ (12 – 41mm) 9/16″ to 1-5/8″ (14 – 41mm) 7/16″ to 2-3/8″ (12 – 60mm) 7/16″ to 2-3/8″ (12 – 60mm) 5/8″ to 3-1/16″ (16 – 77mm)
Depth Max. 1″ (25mm) 2″ (50mm) 2″ (50mm) 2″ (50mm) 2″ (50mm) 2″ (50mm) 6″ (152mm) 3″ (76mm) 4″ (100mm)
Cutter Mounting Bayonet Style 3/4″ Double Flat 3/4″ Double Flat 3/4″ Double Flat or Fusion2™t 3/4″ Double Flat 3/4″ Double Flat 3/4″ Double Flat 3/4″ Double Flat 3/4″ Double Flat
No-Load R.P.M. 450 450 250 / 450 350 / 650 250 / 450 250 / 450 250 / 450 250 / 450 250 / 450
450 / 750
Model Weight 23.8 lbs
(10.8 kg)
28.9 lbs
(13.1 kg)
35 lbs
(15.9 kg)
35 lbs
(15.9 kg)
43 lbs
(19.5 kg)
40 lbs
(18.1 kg)
44.2 lbs
(20.1 kg)
46 lbs
(20.9 kg)
72 lbs
(32.6 kg)
Thru-the-Tool Coolant checkmark checkmark checkmark checkmark checkmark checkmark checkmark checkmark
Available Accessories
Carrying Case Included checkmark checkmark checkmark checkmark checkmark checkmark checkmark checkmark
Swivel Base Optional Optional Optional Optional Optional
#2 Morse Taper checkmark With
Adapter
With
Adapter
Pipe Adapter checkmark checkmark checkmark Manual
Mode
checkmark checkmark checkmark Bracket
Mount
Tap Attachment checkmark checkmark checkmark Manual
Mode
checkmark checkmark checkmark
Vac-Pad™ checkmark checkmark checkmark
Coolant Bottle Optional Included Included Included Included Pressurized Included Included
Countersink Kit checkmark checkmark checkmark Manual
Mode
checkmark checkmark checkmark checkmark
Twist Drill Adapter checkmark checkmark checkmark Manual
Mode
checkmark checkmark checkmark checkmark
Ratchet Drive checkmark checkmark checkmark checkmark checkmark checkmark checkmark
Arbor Extender checkmark checkmark checkmark Manual Mode checkmark checkmark checkmark checkmark
Drill Chuck checkmark checkmark checkmark Manual Mode checkmark checkmark checkmark
RotaLoc™ Spindle Adapter checkmark checkmark checkmark Manual Mode checkmark checkmark checkmark

Choose Your Depth of Cut
