Description
Dimensions
- Tool Size3/4″
- Diameter0.7500″
- Taper Diameter Min0.4060″
- Taper Diameter Min (Metric)10.31mm
- Taper Diameter Max0.7500″
- Taper Diameter Max (Metric)19.05mm
- Flute Length5.0000″
- Flute Length (Metric)127.00mm
- Overall Length7.0000″
- Overall Length (Metric)177.80mm
Specifications
- Surface ConditionBlack & Gold
- MaterialHSS
- Flute TypeSpiral
- Hand of SpiralLeft
- Hand of CutRight
- Reamer StyleCar
- Number of Flutes5
Shank
- Shank ConfigurationStraight
- Shank End FeatureHex
- Shank Square Width1.2500″
- Shank Square Width (Metric)31.75mm
