Description
DETAILS
- Stable speed, even in the toughest applications.
- Fine drill spindle adjustment for convenient machine alignment.
- Double drill motor guides enable use of the longest annular cutters.
- Reversible
- Electronic speed control.
- MT3 interface.
- High magnetic holding force.
- Easy to read convenient magnetic holding force display.
- Integrated coolant tank.
TECHNICAL DATA
TECHNICAL DATA
Power consumption
1,300 W
Power output
730 W
Load speed: 1st gear
120 – 240 rpm
Load speed: 2nd gear
260 – 520 rpm
Tool mount
MT 3
Carbide cutter max. dia.
2-1/2 [65] in[mm]
HSS cutter max. dia.
1-3/4 [45] in[mm]
Cutter max. drilling depth
2 [50] in[mm]
Twist drill max. dia.
1 [25] in[mm]
Tapping
M 20
Max. countersinking dia.
2 [50] in[mm]
Reaming max. dia.
1 [25] in[mm]
Cutter holder
3/4″ straight shank
Cutter change
tool-free
Stroke
5-11/16 [145] in[mm]
Total stroke range
12-3/8 [315] in[mm]
Drill stand adjustment range
1/4 [6] in[mm]
Drill stand angular adjustment
7°
Cable with plug
13 [4] ft[m]
VIBRATION AND SOUND EMISSION VALUES
Sound pressure level LpA
81,6 dB
Measurement uncertainty of the measured value KpA
5 dB
Sound power level LWA
92,6 dB
Measurement uncertainty of the measured value KWA
5 dB
Peak sound value LpCpeak
95,2 dB
Measurement uncertainty of the measured
